Medicontur Bi-Flex ELON

To create minimal optical disturbances, Medicontur invented Wavefront Linking, a non-diffractive technology for a wide range of vision. This proprietary technology is based on a series of central concentric refractive zones varying in curvature and linked by specially designed linking zones.

Wavefront Linking enables light energy to be distributed continuously along the optical axis. Connected focal points result in a singular ELONgated focus, useful across the entire range of vision. With no diffractive rings, Wavefront Linking technology lowers the risk of visual disturbances compared to diffractive EDoF solutions on the market.

Central concentric refractive zones varying in curvature linked by specially designed linking zones. Continuous light energy is distributed along the optical axis with connected focal points, delivering singular elongated focus across the entire range of vision.

The ELON lens is equipped with the proprietary Bi-Flex design for long-term stability and centration. The large contact angle between the lens haptics and the capsular bag wall ensures long-term stability and visual comfort.

SEMTE hydrophobic copolymer material, ensuring high uveal biocompatibility and low levels of glistening.

The Medicontur Bi-Flex ELON lens provides excellent contrast sensitivity along the whole defocus range.

Patients can lead an active lifestyle independent of spectacles. ELON delivers high-quality vision for far and intermediate distances. Glasses may be required for near vision.

Preliminary clinical experience suggests that Medicontur Bi-Flex ELON can be used in presbyopia correction in patients with mild ocular pathologies or previous ocular surgeries.

Non-diffractive Extended Depth of Focus (EDoF) IOLs.  The latest generation of presbyopia-correcting IOLs.

Using several physical or optical principles, ELON IOL aims to satisfy the visual needs of patients who lead an active lifestyle, while minimising the risk of dysphotopsia compared to diffractive technologies.

877PEY preloaded injector system

EDoF single piece, sterile, foldable aspheric hydrophobic acrylic IOL with UV blocker and blue light filter.

Download
Technical specifications
Description & Technical Specs

Medicontur Bi-Flex ELON

877PEY

Single piece, sterile, foldable aspheric hydrophobic acrylic intraocular lens (IOL) with UV blocker and blue light filter. The optic is EDOF. The IOL is available as part of a preloaded injector system.

Power range

Standard: +8.0 D → +30.0 D (0.5 D steps)

Extreme: +31.0 D → +35.0 D (1.0 D steps)

Hydrophobic acrylic with UV blocker and blue light filter

Refractive Index: 1.47

Abbe Number: 58

Design

Optic Diameter: 6mm

Overall Diameter: 13mm

Optic Design: Aspheric – Aberration Neutral Biconvex (+8.0 D → +35.0 D)

Nominal A-constant: 118.9

EDOF Zone: Refraction-based central Wavefront Linking zones

Haptic Design: Posterior vaulting fenestrated C-loops with 0° angulation

PCO Prevention: 360° sharp edge

Shelf Life: 2.5 years after sterilisation

Injection

Estimated Incision Size: 2.2mm

Compatible injector: POB-MA single use | Pre-loaded injector

Constants

SRK/T A-Constant: A = 118.9

Haigis: a0 = 1.32 | a1 = 0.4 | a2 = 0.1

Hoffer Q: pACD = 5.46

Holladay I: SF = 1.7

Barrett Universal II: LF = 1.83

Holladay II: ACD = 5.49 | SF = 1.73



To achieve the goal of creating a true EDoF IOL with minimal optical disturbances, Medicontur developed Wavefront Linking. This proprietary non-diffractive technology is based on a series of central concentric refractive zones varying in curvature linked by specially designed linking zones.

Wavefront Linking causes light energy to be distributed continuously along the optical axis. The focal points are connected, resulting in a singular elongated focus that is useful across the entire range of vision.

Wavefront Linking enables a more flexible modification of light energy distribution that results in higher intermediate light intensity and a wider range of functional vision. Because it contains no diffractive rings, Wavefront Linking lowers the risk of visual disturbances compared to diffractive EDoF solutions.

ELON gives surgeons the opportunity to minimise even mild photic phenomena while providing better intermediate and near vision compared to monofocal IOLs.

This ELON EDoF IOL is an optimal choice for patients who live an active lifestyle and would like to improve their visual quality but would not mind occasionally wearing spectacles for close-up activities.

Prof Srinivasan prefers ELON for his patients who have previously had LASIK, PRK, or other laser vision correction surgery.
